Ubiquiti UniFi Cloud Gateway MAX…

Compact 2.5G Cloud Gateway with 30+ UniFi device / 300+ client support, 1.5 Gbps IPS routing, and selectable NVR storage. Performance may be reduced with PPPoE depending on ISP implementation. Includes full UniFi application suite for device management Manages 30+ UniFi devices and 300+ clients 1.5 Gbps routing with IDS/IPS Multi-WAN load balancing 512 GB NVMe SSD storage for NVR 0.96" LCM status display USB-C powered (adapter included) Mechanical Dimensions 141.8 x 127.6 x 30 mm (5.6 x 5 x 1.2") Weight 519 g (1.1 lb) Enclosure material Polycarbonate Hardware Processor Quad-core ARM Cortex-A53 at 1.5 GHz System memory 3 GB DDR4 On-board storage 512 GB NVMe SSD Management interface Ethernet Bluetooth Networking interface LAN: (4) 1/2.5 GbE RJ45 ports WAN: (1) 1/2.5 GbE RJ45 port IDS/IPS throughput 1.5 Gbps* *Measured with iPerf3 on a DHCP network.

power consumption 16.1W LCM display 0.96" status display Button Factory reset Ambient operating temperature -10 to 40° C (14 to 104° F) Ambient operating humidity 5 to 95% noncondensing Certifications CE, FCC, IC Gateway Features Performance Redundant WAN with failover and load balancing WiFi QoS with UniFi APs Application, domain, and country-based QoS Application and device type identification Additional internet failover with LTE Backup Internet quality and outage reporting Next-generation security Application-aware firewall rules Signature-based IPS/IDS threat detection Content, country, domain, and ad filtering VLAN/subnet-based traffic segmentation Full stateful firewall Advanced networking License-free SD-WAN WireGuard, L2TP and OpenVPN server OpenVPN client OpenVPN and IPsec site-to-site VPN One-click Teleport and Identity VPN Policy-based WAN and VPN routing DHCP relay Customizable DHCP server IGMP proxy IPv6 ISP support LEDs Ethernet Green: link/activity Application Requirements Mobile app UniFi iOS™ and Android™: Version 10.17.2 and later Power method USB type C (5V DC/5A) Supported voltage range 100–240V AC Max.
